CV32-BMS Automotive Supervisor MCU
Low-power 32-bit controller for pack supervision and contactor logic. Hardware CRC, clock supervisor, and dual CAN-FD for redundant communications.
Low-power 32-bit controller for pack supervision and contactor logic. Hardware CRC, clock supervisor, and dual CAN-FD for redundant communications.
Quality note: Specified to meet applicable industry standards. Bureau Veritas certified quality system. Shorter lead-time builds available on qualified demand.
The PDF is the public evaluation brief (specs, pin map, package sketch). The revision-controlled datasheet with SOA curves, land pattern and PPAP pack is issued after an RFQ.
Key specifications
| Core | 32-bit |
|---|---|
| Clock | 120 MHz |
| Flash | 256 KB |
| CAN-FD | 2 channels |
| Supply | 2.7–5.5 V |
| Package | TQFP-48 |
| Temp range | -40 to +150 °C Tj |
Typical applications
- Battery pack supervision
- Contactor control
- Thermal managers
Use-case examples are typical, not a substitute for your design review, SOA analysis, and qualification plan.
Package outline sketch
Reference drawing for layout planning. Use the product brief PDF for notes and the controlled datasheet for the land pattern released to your program.
