CV-PMIC-48A Automotive Multi-Rail PMIC
Five-output power management IC for 12 V automotive body and gateway modules. Sequencing, window watchdog, and load-dump tolerant pre-regulator in a single package to cut discrete count on the primary rail tree.
Five-output power management IC for 12 V automotive body and gateway modules. Sequencing, window watchdog, and load-dump tolerant pre-regulator in a single package to cut discrete count on the primary rail tree.
Quality note: Specified to meet applicable industry standards. Bureau Veritas certified quality system. Shorter lead-time builds available on qualified demand.
The PDF is the public evaluation brief (specs, pin map, package sketch). The revision-controlled datasheet with SOA curves, land pattern and PPAP pack is issued after an RFQ.
Key specifications
| Input range | 4.5 V to 40 V |
|---|---|
| Outputs | 5 (buck + LDO) |
| Peak efficiency | 94% |
| Quiescent current | 28 µA |
| Watchdog | Window, programmable |
| Package | QFN-32 5×5 mm |
| Temp range | -40 to +150 °C Tj |
| AEC-Q100 | Grade 1 intent |
Typical applications
- Body control modules
- Gateway ECUs
- Cluster power trees
- Telematics
Use-case examples are typical, not a substitute for your design review, SOA analysis, and qualification plan.
Package outline sketch
Reference drawing for layout planning. Use the product brief PDF for notes and the controlled datasheet for the land pattern released to your program.
